SPECIFICATIONS
Engine:
5.7 liter LT1 engine. (350 cu. in.)
Horsepower/RPM: 260 @ 5000
Torque/RPM: 330 @ 2400
Fuel System: Sequential fuel injection (SFI)
Compression Ratio: 10.5:1
Exhaust: Dual
Heads: Cast-iron
Cam/valve lift specs.: .417/.429 (int/exh)
Valve springs: 393 lb/in
Valve spring od.: 1.241"
Valve spring inst. ht.: 1.70"
MAF id.: 3.25"
Horsepower/RPM: 260 @ 5000
Torque/RPM: 330 @ 2400
Fuel System: Sequential fuel injection (SFI)
Compression Ratio: 10.5:1
Exhaust: Dual
Heads: Cast-iron
Cam/valve lift specs.: .417/.429 (int/exh)
Valve springs: 393 lb/in
Valve spring od.: 1.241"
Valve spring inst. ht.: 1.70"
MAF id.: 3.25"
Specifications
Chassis:
Body: Body on Frame - Two-sided galvanized steel
body panel (except roof).
Frame: Full Perimeter Steel
Front Suspension: Independent-SLA, Coil Steel Alloy Spring, Steel Anti-Roll Bar, Tuned Shocks.
Rear Suspension: Salisbury 4-Link, Coil Steel Alloy Spring, Steel Anti-Roll Bar, Tuned Shocks.
Steering Type: Power, Internal Gear with Power Piston Vane Type Pump.
Steering Ratio: 12.7:1
Frame: Full Perimeter Steel
Front Suspension: Independent-SLA, Coil Steel Alloy Spring, Steel Anti-Roll Bar, Tuned Shocks.
Rear Suspension: Salisbury 4-Link, Coil Steel Alloy Spring, Steel Anti-Roll Bar, Tuned Shocks.
Steering Type: Power, Internal Gear with Power Piston Vane Type Pump.
Steering Ratio: 12.7:1
Alternator:
Type: Delco CS-144
Amps: 140
Amps@Idle: 72/108
Features: Sealed High Capacity Bearings, Transient Voltage Spike Protection, Vehicle Low Voltage Idle Boost Compatible, Load Responsive Control, Reduced RFI.
Amps: 140
Amps@Idle: 72/108
Features: Sealed High Capacity Bearings, Transient Voltage Spike Protection, Vehicle Low Voltage Idle Boost Compatible, Load Responsive Control, Reduced RFI.
Brakes:
Bosch System 5 Four Wheel Anti-lock
Type: Dual Hydraulic, power system, Disc/Drum
Type: Dual Hydraulic, power system, Disc/Drum
General:
Curb Weight: 4357 lbs.
Wheelbase: 115.9"
overall Length: 214.1"
Overall Width: 77.5"
Overall Height: 55.7"
Head Room (front/rear): 39.2"/37.9"
Shoulder Room (front/rear): 63"/63.4"
Hip Room (front/rear): 57"/56.9"
Leg Room Front (maximum): 42.2"
Leg Room Rear (minimum): 39.5"
Luggage Compartment (cu. ft.): 20.4
Interior Volume (cu. ft.): 114.2
Wheelbase: 115.9"
overall Length: 214.1"
Overall Width: 77.5"
Overall Height: 55.7"
Head Room (front/rear): 39.2"/37.9"
Shoulder Room (front/rear): 63"/63.4"
Hip Room (front/rear): 57"/56.9"
Leg Room Front (maximum): 42.2"
Leg Room Rear (minimum): 39.5"
Luggage Compartment (cu. ft.): 20.4
Interior Volume (cu. ft.): 114.2
Fuel Tank Capacity:
19.1 US Gallons
Aerodynamics:
Coefficient of Drag: .34
Transmission:
Automatic Electronic with Overdrive,
4-speed. (4L60E)
