GENERAL INFORMATION
Impala SS
1994-1996
In 1991, the GM B platform was extensively redesigned, though it retained the same shortened frame design of the 1977 redesign.
The Impala SS badge was resurrected at the 1992 Detroit Auto Show as a concept car designed by GM designer Jon Moss. The vehicle was put into production almost exactly as designed, with the only noticeable cosmetic change being the chrome "bowtie" logo on the grille (vs. red in the concept). A major mechanical difference was the concept car had a GM Performance Parts 8.2 L engine, which was impractical for production. It was replaced with the 5.7 L LT1 engine used in the Chevrolet Corvette, Camaro, and Pontiac Firebird.
The 1994 Impala SS went into production 14 months later at GM's plant in Arlington, Texas. The car was a high-performance version of the Caprice. From a mechanical standpoint, it used the Caprice 9C1 police package as its base and as such got most of the equipment formerly available only to law enforcement and government agencies. This included a sport-tuned suspension with reinforced shocks and struts, a high-capacity upgraded reverse flow cooling system, larger and more powerful four-wheel disc brakes, transmission cooler, dual exhaust, a higher-output electrical system, and other minor mechanical alterations. Not all of the police equipment was carried over however, as the Impala SS did not get the external oil-to-air engine oil cooler, nor were all the body mounts secured (the standard Caprice and Impala SS were assembled at the factory with the front 3 body mounts missing one of the rubber cushions, while the 9C1 was assembled with all rubber cushions in place), although both are popular aftermarket additions to the Impala SS by their owners.
The Impala SS was uniquely fitted with a standard 3.08 limited-slip rear differential and suspension that was an inch lower. A retuned LT1 5.7 L small-block V8 was standard on the Impala SS, making 260 hp and 330 ft·lbf (447 N·m) of torque. The primary difference between the LT1 in the Impala and the LT1 that was in the Corvette and Camaro was that the Impala engine was fitted with cast-iron cylinder heads instead of aluminum ones, and a camshaft that was designed more for low-end torque than high-end horsepower. Another difference was that the Impala LT1 had 2 bolt main bearing caps while the Corvette LT1 had 4 bolt main bearing caps. The transmission used in the car was the 4L60E, an electronically-controlled revision of the previous 700R4 transmission.
Several other cars in the B-body line also shared a similar powertrain: these were the Chevrolet Caprice, Buick Roadmaster, and the Cadillac Fleetwood which all shared the LT1 engine and 4L60E transmission.
Cosmetically, the Impala SS received body-colored trim, which helped reduce the sometimes "bloated" look of the standard Caprice, a unique single-bar grille with no hood ornament, a rear deck spoiler, and, for 1994, a rear quarter panel window insert that bore the Impala logo. It was fitted with 17 inch brushed aluminum wheels with 255/50ZR17 tires. Inside, the car came with a central console with cup holders (1994 and 1995 models) and a storage compartment, leather seats embroidered with the Impala SS logo, and a standard leather-wrapped steering wheel.
For the 1994 model year, it was available only in black with a grey interior. Due to a shortage of the unique 5-spoke aluminum wheels, only 6,303 cars were sold. However, the wheel shortage was remedied for the 1995 model year and 21,434 cars were sold. In 1995, Dark Cherry Metallic and Dark Grey Green were added as exterior color options, and the body paneling on the rear quarter panel was altered to reflect the cosmetic effect formally achieved by a window insert. 1996 was the last year of production with 41,941 units sold. The 1996 Impala SS production went late into the model year; some being produced as late as Dec 17, 1996. It saw some minor interior alterations, with the digital speedometer being replaced by an analog one, along with a tachometer. The shifter was moved from the column to the center console, and mechanically, the car now used the OBD-II computer system.
The entire B/D-body line, consisting of the Chevrolet Caprice, Impala SS, Buick Roadmaster and Cadillac Fleetwood, was discontinued by General Motors, as GM wanted more assembly lines to be able to produce more profitable SUVs. Another fact was that the Caprice was the only B-body with a market share since fleet sales to law enforcement outnumbered sales of all other B-bodies.
As of 2007, 1994-6 Impala SSs (including the Caprice 9C1) retain enthusiast popularity. Some clubs are centered around the Impala and related B-body vehicles. The powerful Corvette-derived engine and large vehicle size lend the vehicle to customization. Some modifications may include turbocharged or supercharged engines, bigger wheels and tires, louder sound systems, and unusual paint jobs.
